Pp Plastic Cable Liquid Water Level Controller 110v 220v Float Switch

Pp Plastic Cable Liquid Water Level Controller 110v 220v Float Switch

Type
1
2
3
Max switch power
10W
70W
5W
Max switch voltage (DC)
200V
200V
175V
Max switch voltage (AC)
140V
250V
125V
Max switch current (DC)
500mA
1000mA
400mA
Max switch current (AC)
500mA
1000mA
280mA
Min breakdown voltage
230V DC
580V DC
200V DC
Max load current
1.75A
2.25A
0.5A
Max contact impedance
100mΩ
90mΩ
120mΩ
Min insulation resistance
106MΩ
106MΩ
106MΩ
Range of working temperature
-40℃~+80℃
-40℃~+80℃
-40℃~+80℃
